DAB EUROSWIM 150 M

The DAB Swimming pool pump is used in residential building service, for filtration in salt water, or chlorine pools or in fishing farms.

• Flow rate maximum: 42 m3/h
• Head up to: 22 m
• Type of pumped liquid: Clean or slightly dirty water with suspended solid bodies, long fibers; particularly aggressive water with high percentages of chlorine/bromine and PHMB (Polyhexamethylene Biguanide) or water treated with chlorine electrolysis process
• Maximum % of glycol: From +4°C to +60°C
• Min. and max. supported liquid temperature: +50°C
• Maximum operating pressure bar / kPa: 2,5 bar / 250 kPa
• Class of protection: IP X5
• Motor insulation class: F
• Impeller/s material: Technopolymer
• Single phase power input: 230 V 50 Hz
• Three phase power input: 3x230 V 50 Hz e 3x400 V 50 Hz

CONSTRUCTION FEATURES OF THE PUMP

• Technopolymer pump body.
• Transparent prefilter cover with bayonet closure.
• Nylon filter. Impeller and diffuser in technopolymer reinforced with glass fibers.
• Butterfly drain plug.

CONSTRUCTION FEATURES OF THE MOTOR

• Two-pole asynchronous motor, available in single-phase or three-phase version.
• Motor casing in die-cast aluminum with cataphoresis surface treatment.
• Single-phase version with thermo-amperometric protection and permanent capacitor inserted as standard.
• Protection by the user for the three-phase version. Mechanical seal in carbon-alumina.

Specification Sheet:

To see specification sheet please Click Here
