- Battery Technical Specification
- Battery Model: SR-EOV24-5.0A-E1
- Number Of Batteries: 1
- Battery Energy: 5.12KWH
- Battery Capacity: 200AH
- Weight: 100Kg
- Dimension: 1190mmL x 600mmD x 184mmH
- Battery Type: LiFePO4
- Battery Rated Voltage: 25.6V
- Battery Working Voltage Range: 22.4VDC - 28.8VDC
- Maximum Charging Current: 150A
- Maximum Discharging Current: 150A
- DOD: 80%
- Designed Life Span: 5000 Cycles
- Inverter Model: SR-EOV24-3.5S-C1
- PV Charge
- Solar Charge Type: MPPT
- Maximum Input Power: 4000W
- PV Charging Current Range: 0A-80A
- PV Operating Voltage Range: 120VDC-500VDC
- MPPT Voltage Range: 120VDC-450VDC
- AC Charge
- Maximum Charge Power: 2240W
- AC Charging Current Range: 0A-80A
- Rated Input Voltage: 220VAC-230VAC
- Input Voltage Range: 90VAC-280VAC
- AC Output
- Rated Output Power: 3500W
- Maximum Output Current: 30A
- Frequency: 50Hz
- Overload Current: 35A
- Rated Output Power: 3500W
- Maximum Peak Power: 6000VA
- Power Factor: 1
- Pated Output Voltage: 230VAC
- Frequency: 50Hz
- Auto Switch Period:
- Communication: RS485 / CAN / WIFI
- Charging Temperature Range: 0 C to 45 C
- Discharging Temperature Range: -10 C to 45 C
- Operation Humidity: 5% to 85%
- Cooling Mode: Force-Air-Cooling @ 60bB
- Ingress Protection: IP20
- Operation Environment: Indoor
- Installation Method: Vertical
Specification sheet:
Product specifications: Click Here
1 x %.12kWh Lithium Battery
Warranty
3 Years Manufacturing Warranty - Inverter
5 Years Manufacturing Warranty - Battery
